The Heavy Duty Column for installing electric vehicle charging stations provides a solution when there is no adjacent wall near the parking space. The pole allows installation of up to two charging stations and up to two arms that lift the cable off the ground to protect both people and the cable. The column is suitable for home charging stations as well as DC fast-charging stations. It also supports the attachment of additional accessories such as a cable retractor.

5-year warranty (document below).

The column is elegant yet robust, requiring no improvisation or metal fabrication work, offered at a competitive price and with immediate availability.

Designed for installation in a private yard near the street or in a parking lot/garage when it is not possible to mount the charging station on a wall, or when there is a need to attach an arm for lifting the cable.

Highly resistant to outdoor conditions thanks to a zinc coating and UV additive for protection against rain and sun. Successfully tested in a salt spray chamber simulating 5 years of outdoor use.

Suitable for carrying charging stations and accessories with a total weight of up to 132lbs/ 60kg. Passed a safety test with a load of 396lbs/ 180kg.

Includes modular rails for mounting charging stations and their accessories (cable winding hook, power switch, charging handle holder, and more), at various heights to improve ease of use.

For user safety and a clean, aesthetic appearance, the power supply cable is concealed inside the pole and enters either above ground through a side opening or fully hidden from below through the base of the column.

Up to two charging stations can be installed on the column; mounting hardware is included.

In addition to the classic anchoring method to a concrete floor, the column can be mounted directly onto a low wall. This is suitable when the charging station must be installed on a wall that is too low for comfortable use, or when the cable needs to be routed over the wall using an arm.

Pole extensions of 15.7" or 31.5" cm are available for purchase as needed.

Height: 94.5"/ 240cm.

Color: Silver-gray.

Installation: Routing the power cable inside the pole and installing the charging station must be carried out by a certified electrician, in accordance with the installation instructions. For questions and clarifications, please contact support.

Parallel and previous versions: EV240P.
